IL810T-3E: Single Channel High-Speed, DC-Correct Isolator, 2.5 kV, SOIC8

IL810T-3E: Single Channel High-Speed, DC-Correct Isolator, 2.5 kV, SOIC8

Part Number
IL810T-3E

Input
CMOS

Output
CMOS

Total Channels
1

Transmit Channels
1

Receive Channels
0

Speed (Mbps)
110

Max. Temperature (°C)
125

Isolation Voltage (Vrms)
2500

VDE Certification
V 0884-17

DC Correct
Yes

Package
SOIC8

Description:

The IL810T-3E is NVE's high-speed, DC-correct, single-channel isolator, with best-in-class specifications:
• 125 °C max. operating temperature
• 110 Mbps
• 10 ns propagation delay
• DC-correct; deterministic power-up
• 50 kV/µs typ.; 30 kV/µs min. transient immunity
• IEC 60747-17 (VDE 0884-17):2021-10 certified
• 44000-year barrier life
• Low EMC footprint

The part is an 8-pin SOIC package.

1 - 9 $4.32

10 - 24 $4.04

25 - 99 $3.53

100 - 499 $3.06

500 + $2.93

Qty:

1315 in stock

$4.32
