Award-winning NVE products direct from the manufacturer with no minimum order and no handling charge.
Most orders qualify for $9.95 flat rate ground shipping within the U.S. and $49.95 for FedEx International Economy outside the U.S.
In-stock parts ship within one business day.
Featured Products
Input:
CMOS
Output:
CMOS
Total Channels:
4
Transmit Channels:
3
Receive Channels:
1
Speed (Mbps):
110
Max. Temperature (°C):
125
Isolation Voltage (Vrms):
7 kVrms
VDE Certification:
V 0884-17
Intrinsically Safe:
IECEx/ATEX
Package:
SOIC16WB
Part Number:
IL717VE
Bus:
RS-485
Duplex:
Half
Bus Load (Unit Load):
1/5
Bus Voltage (V):
3.3
Integrated DC-to-DC (V):
3.3-to-3.3
Speed (Mbps):
40
Max. Temperature (°C):
85
Isolation Voltage (Vrms):
2500
VDE Certification:
V 0884-17
Approvals:
CISPR 32 Class B
, PROFIBUS
Package:
SOIC16WB
Part Number:
IL4685E
Technology:
GMR
Magnetic Polarity:
Omnipolar
Magnetic Operate Point (mT):
1
Magnetic Release Point (mT):
0.5
Duty Cycling:
Continuous
Output:
Sink
Direction of Sensitivity:
Cross-axis
Supply Voltage (V):
0.9 to 2.4
Supply Current @1.5 V (µA):
35
Output Current (mA):
0.1
Max. Temperature (°C):
85
Package:
0.65 x 0.65 mm WLCSP
Part Number:
AHL925-20E
Sensor Function:
Magnetometer
Technology:
TMR
Magnetic Polarity:
Bipolar
Field Measurement Range (mT):
-2 to +2
Resolution (bits):
24
Magnetic Operate Point (mT):
Programmable
Magnetic Release Point (mT):
Programmable
Output:
I²C; Comparator
Sampling Speed (Sps):
300
Direction of Sensitivity:
Cross-axis
Supply Voltage (V):
1.68 to 3.6
Supply Current @ 3.3 V (µA):
1500
Max. Temperature (°C):
125
Package:
2.5 x 2.5 mm DFN6
Part Number:
SM324-10E
Technology:
TMR
Magnetic Polarity:
Bipolar
Field Measurement Range (mT):
-2 to +2
Current Measurement Range (A):
1-200
Sensitivity (mV/V/mT):
120
Output:
Bridge
Min. Detectable Field (µT):
1
Direction of Sensitivity:
Cross-axis
Supply Voltage (V):
0 to 5.5
Bridge Resistance (kΩ):
20
Current Sensing Mode:
Over-trace
Max. Temperature (°C):
125
Package:
2.5 x 2.5 mm DFN6
Part Number:
ALT024-10E
Technology:
TMR
Output:
Sin/Cos
Bridge Configuration:
Half Bridge
Supply Voltage (V):
0 to 5.5
Bridge Resistance (kΩ):
50
Max. Temperature (°C):
150
Package:
SOIC8
Pole Pitch (mm):
5
Part Number:
AET500-02E
Technology:
TMR
Magnetic Polarity:
Bipolar
Field Measurement Range (mT):
-0.25 to +0.25
Current Measurement Range (A):
0.1 to 10
Sensitivity (mV/V/mT):
500
Output:
Bridge
Min. Detectable Field (µT):
0.1
Direction of Sensitivity:
Cross-axis
Supply Voltage (V):
0 to 5.5
Bridge Resistance (kΩ):
20
Current Sensing Mode:
Over-trace
Max. Temperature (°C):
125
Package:
2.5 x 2.5 mm DFN6
Part Number:
ALT021-10E
Technology:
TMR
Output:
Half-Bridge
, Sin/Cos
Supply Voltage (V):
0 to 5.5
Bridge Resistance (kΩ):
15
Max. Temperature (°C):
150
Package:
2.5 x 2.5 mm DFN6
Pole Pitch (mm):
2
Part Number:
AET200-10E
