IL260E: 5-Channel (all same direction) Isolator, 2.5 kV, Wide SOIC

  • Part Number
  • IL260E
  • Total Channels
  • Transmit Channels
  • Receive Channels
  • Max. Temperature (°C)
  • Isolation Voltage (Vrms)

Description:

The IL260E is a 3.3/5.0-volt, 5 channel isolated, 110 Mbps, CMOS-compatible logic buffers with 10 ns propagation delay, 3 ns pulse width distortion, 2500 Vrms isolation and 30 kV/microsecond transient immunity. 16-pin, wide-body (0.3"-wide) SOIC package.

The "E" suffix indicates this part is lead (Pb) free.

$8.54
1 - 9 $8.54
10 - 24 $7.98
25 - 99 $6.99
100 - 499 $6.05
500 + $5.78
12172 in stock
