IL422E: Isolated RS422 Transceiver, 2.5 kV, Wide SOIC
IL422E: Isolated RS422 Transceiver, 2.5 kV, Wide SOIC
Part Number
IL422E
Bus
RS-422/RS-485
Duplex
Full
Bus Load (Unit Load)
1
Bus Voltage (V)
5
Speed (Mbps)
35
Max. Temperature (°C)
85
Isolation Voltage (Vrms)
2500
VDE Certification
V 0884-17
Package
SOIC16WB
Data Sheet
(.pdf)
Electronic Data Automation
(External Link)
Description:
Galvanically-isolated full-duplex RS 422 interface in a 0.3"-wide 16-pin SOIC package. 2500 Vrms isolation and 20 kV/microsecond transient immunity.
RoHS compliant.
Lead-free product information
$
12.58
1 - 9
$
12.58
10 - 24
$
11.75
25 - 99
$
10.29
100 - 499
$
8.91
500 +
$
8.51
Qty:
4966 in stock
Add to Cart
In your cart
Add to Cart
Notify me when in stock
