IL41050TTE: Basic Isolated CAN Transceiver, 2.5 kV, Wide SOIC

  • Part Number
  • IL41050TTE
  • Bus Load (Unit Load)
  • 1
  • Bus Voltage (V)
  • 5
  • Speed (Mbps)
  • 4
  • Max. Temperature (°C)
  • 125
  • Isolation Voltage (Vrms)
  • 2500

Description:

The IL41050TT is a low-cost, basic CAN transceiver without Vref output and silent mode input pins. 2.5kV isolation; 125C; 180 ns typ. loop delay; ISO 11898 compliant; >110 node fanout; 1 Mbps; 3.3 V or 5.0 V input logic.

16-pin wide-body (0.3'') RoHS SOIC package with full 8 mm creepage.

$3.62
1 - 9 $3.62
10 - 24 $3.38
25 - 99 $2.96
100 - 499 $2.57
500 + $2.45
410 in stock
