NVE's ADL021-14E Nanopower Switch integrates GMR sensor elements with digital onboard signal processing and duty-cycling electronics. The Nanopower Switch is extremely small and extremely low power.
Features:
- Ultraminiature 1.1 mm x 1.1 mm x 0.35 mm DFN4 package
- 2.4 to 4.2 V
- Typical Power Consumption 192 nW at 2.4 V
- 55 Hz Typical Update Frequency
- Digital Switch Output
- Integrated Duty-Cycling
Applications:
- Battery-Powered Devices
- Portable Instruments
