IL700-1-01: QSOP 4- and 5-Channel Isolator Evaluation Board
This evaluation board lets you try the world’s densest high-performance isolators.
The board includes five high-performance QSOP isolators:
- IL715-1E: 4-Channel (all same direction)
- IL716-1E: 4-Channel (2 each direction)
- IL717-1E: 4-Channel (3 transmit, 1 receive)
- IL260-1E: 5-Channel (all same direction)
- IL261-1E: 5-Channel (4 transmit, 1 receive)
IsoLoop QSOP isolators have best-in-class performance:
- 110 Mbps
- 2500 V isolation
- -40°C to +100°C
- 3 V to 5.5 V operation
- 44000 year barrier life
- True 4 mm creepage
