DB001-00E: Signal Processing IC MSOP

  • Part Number
  • DB001-00E

Description:

NVE DB001-00E signal processing IC is designed to work with NVE AD9xx series GMR switch with short circuit protection. This combination provides a high-current switched output that corresponds to the sensor input. The DB001-00E functions as the front end of a complete sensor assembly, and includes protection against short circuits and high voltage transients from capacitive and inductive loads. The parts also feature thermal shutdown circuitry and reverse battery protection. They provide a regulated output voltage for the sensor and other components in the assembly, and an LED driver to indicate an "ON" condition.

Features:

  • High Current Output
  • Reverse Battery and Transient Protection
  • LED Driver
  • Excellent Temperature and Voltage Performance
  • Small, Low Profile Surface Mount Packages

Note: Parts must be purchased in multiples of 100 when purchased in quantities of 100 or more. Larger quantities are subject to NVE standard lead times.



$4.25
1 - 9 $4.25
10 - 99 $2.95
100 - 499 $2.10
500 + $1.54
6659 in stock
