AAT009-10E: Angle Sensor, 6 MOhm, DFN6

  • Part Number
  • AAT009-10E
  • Magnetic Field Operating Range (mT)
  • Supply Current @ 3.3 V (µA)
  • Bridge Resistance (kΩ)
  • Max. Temperature (°C)

Description:

-10E Angle Sensors use Tunneling Magnetoresistance (TMR) technology for ultralow power, high output signal, and a wide airgap tolerance. Sine and cosine outputs provide full quadrature. The AAT009-10E version has the highest device resistance in the AAT product family (6 megaohms typ.), for the lowest power consumption.

The angle sensors are typically used with a split pole magnets such as NVE part no. 12249 or 12426.

An Evaluation Kit is available with an angle sensor, circuit board, unity-gain buffer amplifier, split-pole magnet, and a plastic magnet locating fixture.
$8.94
1 - 9 $8.94
10 - 99 $6.75
100 - 499 $4.85
500 + $3.42
3869 in stock
