IL41050WB-01: Isolated Wide-Body CAN Evaluation Board

  • Part Number
  • IL41050WB-01
  • Bus Load (Unit Load)
  • 1
  • Bus Voltage (V)
  • 5
  • Speed (Mbps)
  • 1
  • Max. Temperature (°C)
  • 125
  • Isolation Voltage (Vrms)
  • 2500

Description:

The isolated CAN Evaluation Board provides a complete isolated Controller Area Network node using NVE popular IL41050TAE isolated wide-body CAN transceiver with true 8mm creepage.

The board is fully ISO 11898 CAN compliant and accommodates 3V - 5.5V supplies. It provides screw terminal connections, termination resistors, and pull-up resistors.
$49.95
50 in stock
