AAH002-02E-EVB01: 1 mT SOIC8 GMR Magnetometor Breakout Board

  • Part Number
  • AAH002-02E-EVB01
  • Sensitivity (mV/V/mT)
  • Min. Detectable Field (µT)
  • Bridge Resistance (kΩ)
  • Max. Temperature (°C)

Description:

A 0.8 x 0.4 inch (21 x 10 mm) breakout board with the AAH002-02E ultrahigh-sensitivity 0.6 to 3 mT linear range GMR analog bridge magnetometer. The board has a pre-soldered sensor and footprints for a standard 0.1" (2.54 mm) header and a common, 1 mm pitch card-edge connector.

The board can be powered by a 0 to 12 V supply and provides a differential output voltage proportional to the applied magnetic field.
$19.95
50 in stock
