NVE is number 68
in the new Minneapolis / St. Paul Business Journal rankings of Minnesota’s
Top 75 Public Companies. More » |
|
|
|
NVE will be closed
May 27
for Memorial Day. |
|
|
|
|
|
|
 |
|
|
Detecting
Tiny Gear Teeth |
|
|
ABL-Series Gear-Tooth
sensors can detect sub-millimeter pitch gear teeth. We did a demonstration to
prove it to skeptical customers.
We use an ABL006 Gear-Tooth sensor biased by an inexpensive ferrite magnet.
A high-speed motor spun a fine-tooth gear, and we could vary the motor speed.
A digital meter displayed the speed measured by the sensor, and a microcontroller
ran the motor and read the sensor.
The demonstration gear was module 0.26 mm; the pitch was 0.83 mm, and
tooth depth was only 0.55 mm:
The sensor provided accurate speed measurement from DC to 10,000 RPM. This requires
a fast, sensitive sensor, and ABL Gear-Tooth sensors fit the bill.
Key features and specifications include:
• Sensitive to small teeth
• 1 MHz operating frequency
• Single- and dual-bridge versions
• Up to 30 V supply
• 150°C operating temperature
• Miniature MSOP8 and 2.5 mm x 2.5 mm TDFN6 packages
Download
GT Sensor Catalog »
|
|
|
|
In
the News |
|
|
An article on magnetic
angle sensors and magnets in Magnetic Business & Technology:
“TMR sensors are more sensitive and have wider operating field ranges
than Hall-effect sensors.”
Read »
A paper in the latest edition of the IEEE Sensors Journal, titled “Non-Invasive
Measurement of Glaucoma Disease at Earlier Stage Through GMR Sensor AH Biomagnetic
Signal From Eye and RADWT Algorithm,” describes NVE sensors to measure
the biomagnetic signal of the aqueous humor for glaucoma detection.
Abstract
»
|
|
|
|
German
Subtitles |
|
|
 |
|
| “Frau
Daniella” |
|
Many of NVE’s most popular
YouTube
videos now have German subtitles available—bad puns and all.
Thanks to our friends at long-time distributor Hy-Line
Power Components for their clever translations.
YouTube
»
|
 |
|
Recent
Conferences |
|
|
NVE distributor K.K. Rocky
demonstrated NVE smart sensors at the Embedded Systems Expo (ESEC Spring) in Tokyo.
|
|
|
Upcoming
Exhibitions |
|
|
 Power
Conversion and Intelligent Motion (PCIM),
May 7 to 9, Nürnberg, Germany.
NVE distributor Hy-Line Power Components (stand 9-519) will display our products,
including the new IL01x Low-Power Isolators
and IL2985E
Low-Power Transceivers.
PCB Design & Manufacturing Live, May 9, 2019, Silverstone Circuit,
Northamptonshire, England in cooperation with distributor Rhopoint Components.
Sensors Expo and Conference
June 25 to 27, San Jose, Calif.
Booth 1344 in the IoT and Wireless Pavillion. |
|
