Sensor and Isolator News--Jan. 7, 2025
Special Year-End Issue
   • New Products
   • 2024 Papers
   • The Year’s Top Videos

NEW!2024 New Products
ALT521 Transfer Function

World’s Most Sensitive Ultraminiature Rotation Sensor
The new ALT521-10E sensor has two independent magnetic sensing axes, each with a high-sensitivity 140 mV/V/mT output. The sensor can detect rotating fields as small as 0.1 µT.


Omnidirectional Sensing


Omnidirectional Sensors
Magnetoresistive sensors are sensitive in-plane, while Hall effect sensors are sensitive perpendicular to the IC plane. NVE’s amazing omnidirectional sensors combine the best of both worlds—sensitive in both directions and anything between.



ALT021-10E-EVB02

Amplified Ultrasensitive TMR Sensor Evaluation Board
The new evaluation board includes an ultrasensitive ALT021-10E TMR magnetic sensor and a 5x amplifier. The 13 x 8 mm PCB has a remarkable sensitivity of 2.5 V/V/Mt.


MSOP Isolators

The World’s Smallest 2500-Volt Isolators
V-1 Series MSOP8 isolators are just three millimeters square—less than an eighth of an inch—but still feature 2500 Vrms VDE 0884-17 and UL 1577 isolation ratings.


Breakout Boards
New Sensor Breakout Boards
Now available for most NVE sensors, the 0.8 x 0.4 inch (21 x 10 mm) boards have pre-soldered sensors, bypass capacitors if required, 0.1" headers, and 1 mm-pitch edge connectors.

H-bridge Arduino Shield

Angle/Rotation Sensor Arduino Shield
The Shield is compatible with all 12 of NVE’s TMR angle and rotational sensor breakout boards.

A magnet fixture allows the magnet to be positioned on-axis or in one of four off-axis positions. Sixty RGB LEDs indicate the angle, and colors indicate direction of rotation.


Current Sensor Eval Boards
Noncontact Current Sensor Evaluation Boards
These current-sensing boards have pre-soldered sensors, screw terminals, 0.1" headers, and 1 mm-pitch edge connectors. Three current ranges are available: 0 to 1 amp, 0 to 7 amps, and 0 to 50 amps.

7 kV Isolation

7 kV Isolators
IL700VE-Series isolators were upgraded to an incredible 7 kV reinforced isolation, the best in class by far.


DFN4

The World’s Smallest High-Sensitivity Magnetic Sensor
A TMR magnetometer sensor with best-in-class sensitivity of 200 mV/V/MT and up to 0.1 µT detectivity was introduced in a 1.1 x 1.1 mm DFN4 package. The new part can be connected directly to ADC or microcontroller analog inputs.


WLCSP

WLCSP Magnetic Switches
Several 1.5-volt magnetic switches were introduced in ultraminiature Wafer-Level Chip-Scale packages (WLCSPs). The new parts are available with a variety magnetic operate points, with or without duty cycling.

2024 Papers
Development of a Proximity Contactless Ammeter Based on GMR sensors for Measuring Direct Currents
Measurement: Sensors, Dec. 26, 2024.
Two AAL002-02 GMR sensors are used to make a precise current sensor.

Exploring Biomagnetism for Inclusive Vital Sign Monitoring: Modeling and Implementation

ACM MobiCom 2024, Oct. 2024.
An ALT021 TMR sensor is used to detect heartrate and respiration in a smartwatch platform.

Real-time Biomolecule Detection Using GMR Chip-based Sensor with Green-synthesized Fe3O4/rGO Nanocomposites as Magnetic Labels
Sensors and Actuators A: Physical, Sept. 1, 2024.
An AAL024 GMR sensor combined with an Arduino is used to detect blood proteins.

Commercial Chip-based Tunneling Magnetoresistance Sensor for Green-synthesized Magnetic Nanoparticles Assay
Sensors International, July 28, 2024.
An ALT025 TMR sensor interfaced to an Arduino detects magnetic nanoparticles for biosensing.

Contactless Position Measurement of an Electrical Conductor using GMR Sensors
2024 IEEE Sensors Applications Symposium, July 23, 2024.
An AA002 GMR sensor is used to determine the position of a wire to a resolution of 10 microns, with applications in wire-sawing and musical instruments.
2024 Top YouTube View Rates
Chessboard Based on GMR Switches
2 World’s Fastest Isolators Rated to 7 kV Isolation
3 Ultrasensitive TMR Magnetometer
4 H-Bridge Evaluation Board
5 Pneumatic Cylinder Servo Using Smart Sensors
