NVE was recently granted U.S. patent number 9,322,889 titled “Low Hysteresis High Sensitivity Magnetic Field Sensor” related to TMR sensors.

See story at right for more information about one of our state-of-the-art TMR products.

New YouTube Videos
Ridiculously Low Power Angle Sensor
AAT001 Sensor+Test Demo
High-Sensitivity Magnetic Sensor Demo for
2016 Sensor+Test Fair
Rotation Sensor
Product Preview

Independence Day
4th of July
NVE will be closed Monday, July 4 for the Independence Day holiday.
NEW! Ridiculously Low-Power
Angle Sensor
6 MΩ Device Resistance
Angle Sensor
NVE has taken low power to unprecedented levels with the AAT009-10E Ultra-Ultra-Low Power Tunneling Magnetoresistance (TMR) Angle Sensor.
AAT-Series Operation
The New AAT009-10E Ultra-Ultra-Low Power Angle Sensor
AAT sensors measure angular position based on rotating magnetic fields. Typical applications include rotary encoders, and motor shaft position sensors, and Internet-of-Things end nodes.

Key AAT009 features include:
  • 6 MΩ typical device resistance for ultralow power consumption
  • 0.5° maximum angular measurement error (fixed bias)
  • 200 mV/V peak-to-peak output signals
  • Wide magnet airgap tolerance
  • Sine and cosine outputs for direction detection
  • Ultraminiature 2.5 mm x 2.5 mm x 0.8 mm TDFN6
The AAT009 can run years on a single button cell. The sensors detect and maintain absolute position information, and immediately power up in the correct position after power is restored.
There are now three AAT-Series sensors:
 Typ. Device Resistance Features
AAT001 1.25 MΩ Ultra-low power
AAT003 40 kΩ  Ideal for interface to microcontrollers
AAT009 6 MΩ Ultra-ultra-low power

All three part types are in stock and available for immediate delivery.

 Buy Online

Evaluation Kits
Evaluation kits are available for each of the AAT-Series sensors:

AAT009 Evaluation Kit
 Buy Online

BlueberriesHere’s a demo of AAT sensors, including the new version, powered by small fruits:
