New Products
SMPS Demo Boards
----

----
New Patents
Patent 9,030,200—
“Spin Dependent Tunneling Devices With Magnetization States Based on Stress Conditions.”

Links to NVE Patents >
----

----
NVE Growing
NVE recently announced product sales increased 29% in its most recent quarter.

More Info >
----

----
Moving Up
Star Tribune 100
Sales growth drove NVE’s impressive move up eight notches in this year’s recently-published Star Tribune 100 rankings of the largest companies in Minnesota.

More Info >
----
Featured Products

ULLGA Nanopower Sensors

ADL-Series Magnetic Switches are NVE’s smallest packaged parts at just 1.1 mm x 1.1 mm x 0.45 mm, and use just nanowatts.
ADL-Series Sensors fit on the head of a pin
ADL-Series Sensors fit
on the head of a pin.


The output is configured as a magnetic “switch,” where the output turns on when a magnetic field is applied and off when the field is removed. The field can be either polarity, and the magnetic operate point is extremely stable over supply voltage and temperature.

Internally duty cycled versions (the ADL0xx and ADL1xx Series) reduce power consumption. An integrated latch ensures the output is available continuously. Two duty-cycle frequencies are available, offering a tradeoff between update frequency and power consumption. Continuously-operating versions (the ADL9xx Series) are also available.

ADL0xx-14 Functional Block Diagram ADLxxx-14 Functional Block Diagram

Continuously-operating versions consume much less than a milliwatt, while duty-cycled versions use less than a microwatt.

ADL-Series parts are ideal for battery-powered devices such as gas and water meters, portable instruments, or anyplace where extremely low power is required.

Key specifications are:
  • 1.1 mm x 1.1 mm x 0.45 mm ULLGA package
  • 2.4 - 3.6 V supply voltage
  • As low as 72 nW power consumption at 2.4 V
  • 20, 28, or 40 Oersted operate points
  • Current-sinking output up to 100 µA
  • -40°C to +125°C temperature range

Part Type Magnetic
Operate Point
(typ.)
Power
Consumption
(typ. at 2.4 V)
Update
Frequency

(typ.)
ADL021-14E 20 Oe 192 nW 55 Hz
ADL024-14E 28 Oe 192 nW 55 Hz
ADL121-14E 20 Oe 72 nW 30 Hz
ADL124-14E 28 Oe 72 nW 30 Hz
ADL921-14E 20 Oe 84 µW Continuous
ADL924-14E 28 Oe 84 µW Continuous

All of these part types are in stock and available for same-day shipment, with no minimum order.

 Buy Online

Recent Exhibitions

At Sensor+Test 2015, customers "forgot reed switches" and gave the thumbs up to NVE magnetic switches:

.Forget reed switches

PCIM Europe
At PCIM Europe, the company highlighted new MSOP and QSOP Isolators.



ESEC
At the Embedded Systems Expo & Conference, NVE highlighted QSOP and MSOP isolators, and had live angle-sensor demonstrations.
