Application Corner |
|
|
Remembering Magnets
Humble magnets are sometimes forgotten in sensor systems. But the right magnet can make all the difference in sensor system performance, often at low cost. Watch our new video for an overview:
Magnet Configurations
Magnets can be often used to activate a magnetic sensor, as with a simple proximity sensor, or to bias a sensor where the field is deflected by ferromagnetic material. For example, GMR Switch Sensors are often activated with a magnet and GT Gear-Tooth Sensors are usually operated with a bias magnet.
Material Grades
Ceramic and Alnico magnetic materials are graded between one and eight. Grade 1 materials are non-oriented or isotropic. In general, higher grades are more fully oriented (anisotropic) and have higher field strengths. Magnet cost also tends to increase with material grade.
Materials
Ceramic (ferrite) magnets are made of strontium carbonate and iron oxide.
Grade 1 have the weakest magnetic field strengths, grade 5 are inexpensive and popular with our customers, and grade 8 have good field characteristics for sensor systems and are still relatively inexpensive.
Alnico refers to aluminium-nickel-cobalt alloys. Alnico magnets have working temperatures above 1,000°F (538°C). Alnico grade 8 magnets provide a very stable field over wide temperature ranges, making them the preferred choice for high temperature application.
Rare-earth magnets (samarium-cobalt or neodymium-iron-boron) are relatively expensive and have very high field strengths. The high field strengths are generally not necessary in NVE sensor systems and may saturate sensors, resulting in no output.
Sizes and Shapes
There are a myriad of magnet sizes and shapes. Some of the more common among our customers are bar magnets around 1/2 inch long and disk magnets 1/8 to 1/4 inch in diameter.
Specialty Magnets
Split-pole magnet
|
Split-pole disk magnets are typically used for
angle sensors such as AAT001 Angle Sensors, although bar magnets are also used. Split-pole magnets have poles on opposite sides of the diameter rather than top and bottom as with a conventional disk magnet (see figure at right).
Ring magnets have multiple poles around the diameter and can be used for rotational or course-angle sensing. Ring magnets are common in ABS systems, for example, and can be used with GT Sensors.
NVE stocks small quantities of several popular magnet types for prototyping and development.
