NVE Sensor and Isolator News
    November 2019 Electrifying  News  From  NVE
In This Issue
TMR Magnetic Switches

Smart Sensor Breakout Boards

Upcoming Exhibitions

Quick Links
Sensor Selector Guide

Isolator Selector Guide

Online Store

Contact Us

New YouTube Videos
Fast, low-power TMR Switches
Intrusion Detection Using an SM124 Smart Sensor
Reciprocating Actuator Using an SM124 Smart Sensor

“Spin” Back
Spin Back
 Saving Time
ends Sunday, November 3. “Spin” your clocks back an hour.

NVE will be open on Veterans’ Day Observed (Monday, November 11).
We will be closed Thursday and Friday, November 28 and 29 for the Thanksgiving holiday.
NEW! 1.5-Volt Nanopower TMR
Magnetic Switches
Revolutionary new AHT-Series Tunneling Magnetoresistance (TMR) magnetic switches are low-voltage, nanopower, high speed, and ultraminiature.

Single-Cell Operation
AHT-Series sensors operate as low as 0.9 volts, so they can be powered by single-cell alkaline batteries.

Ultralow Power
TMR technology provides ultralow power. Typical AHT-Series quiescent supply current is just 1 µA, even with no duty cycling. That’s less than the self-discharge rate of typical button cells, making the new sensors ideal for battery applications such as utility meters or portable instruments.

Speed and Wide Bandwidth
Continuous operation without duty cycling means the sensors are fast, and can switch at more than 1.5 kHz.

Magnetic operate points are as low as 1.5 mT (15 Oe).

Configured as Switches
Outputs are configured as magnetic “switches,” turning on when a magnetic field is applied and off when the field is removed. The field can be either polarity, and the magnetic operate point is extremely stable over supply voltage and temperature.

AHT-Series Sensors fit on the head of a pin
AHT-Series Sensors fit
on the head of a pin.
AHT sensors are also NVE’s smallest parts at just 1.1 mm x 1.1 mm x 0.35 mm (0.043 x
0.043 inch)

Key Specifications
  • 0.9 to 1.8 V
  • 1 µA supply current
  • 1.5, 2.2, 3.2, or 4.5 mT operate points
  • Open-drain output
  • -40°C to 85°C temperature range

In Stock
Four AHT-Series part types are available:
Part Type
(click for
Typical Magnetic
Operate Point
AHT925-14E 1.5 mT
AHT924-14E 2.2 mT
AHT923-14E 3.2 mT
AHT922-14E 4.5 mT
Download the AHT Datasheet »
Buy Online

Here’s a demonstration of the low power and high speed of the new part:

NEW! Smart Sensor Breakout Boards
NVE expanded its Smart Sensor support ecosystem with breakout boards for all four NVE Smart Sensors. The boards include a Smart Sensor, six-pin header, and a bypass capacitor, making it easy to evaluate the sensors and build prototypes:The AG958-07E Breakout Board also has a connector to for use with the AG955-07E Self-Contained SM124 Programmer or with customers’ own boards.

AG958 AG959 AG960 AG957
SM124 General-Purpose Smart Magnetometer Breakout Board
SM225 Precision Smart Magnetometer Breakout Board
SM324 Ultraprecise Smart Magnetometer Breakout Board
ASR002 Smart Angle Sensor Breakout Board
In addition to the breakout boards, NVE offers Smart Sensor evaluation kits that include evaluation boards with microprocessor USB interfaces to Windows-based computers.
ISO9001 and IATF 16949 Renewed
IATF 16949
NVE’s ISO9001 certificate and IATF16949 Letter of Conformance have been renewed.

The IATF Letter certifies that NVE has established and applies a Quality Management System for components for the automotive industry.

NVE makes a number of products for automotive applications, including CAN and CAN FD isolated transceivers, as well as a wide range of magnetic sensors.
Conferences and Exhibitions
NVE researchers will present paper titled, “Noise
  Optimization in Magnetic Tunnel Junctions,”
  at the Magnetism and Magnetic Materials Conference November 8 in Las Vegas.

Embedded Technology & IoT Technology
NVE distributor K.K. Rocky will be exhibiting sensors, isolators, and the popular smart-sensor based xylophone at Embedded Technology & IoT Technology, November 20 to 22, booth C-46, Yokohama, Japan.
