NVE Sensor and Isolator News
----
    November 2016 Electrifying  News  From  NVE
----
----
In This Issue
Nanopower Magnetic Sensor Evaluation Kit

Exhibitions

New Demo Kits

Halloween Application Corner:
2-Wire Interfaces
----

----
Quick Links
Sensor Selector Guide

Isolator Selector Guide

Online Store

Contact Us
Twitter
Google+
YouTube
----

----
Document Updates
Sensor Catalog
Freshly updated with new products, the short-form Sensor Catalog summarizes parts and specifications in each of NVE’s six sensor product lines.

Download Sensor Short-Form Catalog >
----

----
New YouTube Videos
ADL021
Mini Demo Boards
Nanopower Sensor Demonstrator
New ADT-Series TMR Rotation Sensors
Nanopower magnetic sensors run (almost) forever on a watch battery
GMR Sensor Demonstration
----

----
“Rotate” Back
Spin Back
Daylight
 Saving Time
ends Sunday, November 6. “Rotate” your clocks back an hour.
----

----
Holidays
Turkey
NVE will be closed Thursday and Friday, November 24 and 25 for the Thanksgiving holiday.

We will be open Veterans’ Day (Friday, November 11).
----
NEW!Nanopower Magnetic Sensor Evaluation Kit

The ridiculous low power of NVE's ADL-Series nanopower magnetic sensors is shown with an analog meter driven by an amplifier with a gain of 1000, providing a 100 nanoamp scale.

The self-contained demonstrator runs on a three-volt coin cell, with each of the three ADL sensor power ranges—the continuous duty ADL921; and the ADL021 and ADL121, which are internally duty-cycled for power consumption in the nanowatts.

In addition to ridiculously low power, ADL-Series sensors are the most sensitive and smallest sensors in their class, with magnetic operate points as low as 20 Oersteds and parts that fit on the head of a pin.


Key ADL-Series sensor features are:
  • Sensitive (as low as 20 Oersted)
  • Ultralow power (as low as 72 nW)
  • Ultraminiature 1.1 mm package

ADL sensors and demonstrators are in stock for immediate delivery.

ADL Demonstrator Manual >

Buy ADL Sensors

Upcoming Exhibitions

Electronica
NVE staff will be supporting our distributor IS-LINE GmbH at Electronica, November 8-11, Munich Trade Fair Centre, Hall A4, stand 415.

New Demo Kits

 AG941-07E    AG941-07E: ADL-Series Evaluation Kit
 AG040B    AG040B: ADL041 Mini Eval Board
 AG932-07E    AG932-07E: ADT002 Rotation Sensor Eval Kit

AG940-07E
    AG940-07E: Digital/ Analog/ Omnipolar/ Bipolar
    Sensor Demo Board



Halloween Application Corner
Bat
Non-Frightening Two-Wire Interfaces

Two-wire sensor interfaces can be frightening, but NVE parts make them easy.

With the sensor off, the two-wire interface circuit must draw a minimal residual current, typically about 1.5 mA. With the sensor on, the circuit has to provide enough current to drive a significant load such as a motor or solenoid.

This reference circuit uses an NVE DC001-10 regulator to wide operating latitude over the input voltage range:

Two-Wire Reference Circuit Using a Voltage Regulator Two-Wire Reference Circuit

The residual current is dominated by the regulator’s quiescent current, which is less than 1 mA and relatively constant over input voltage. A Zener diode can be used instead of a voltage regulator in many applications.

 2-Wire Interface video (03:30) >
